Pyroflex fire protection hose

Application:

Typically used for fire protection of process hoses. Heat resistant up to 1100°C for short periods and compatible with various hoses, pipes and installations in different sizes (see sizes here).

Pyroflex provides maximum protection in industrial environments where the risk of fire is high. The robust design not only withstands extreme temperatures, but also provides flexibility for easy handling and installation.

Construction:

Made of silicone-coated fiberglass.

Technical specifications

Temperature:

Max 260°C - briefly up to 1100°C.

Standards:

EN45545 & DIN5510-2.

Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
0429790012
12,0
15,4
Red
25,0
MTR
0429790020
20,0
24,6
Red
20,0
MTR
0429790025
25,0
30,2
Red
20,0
MTR
0429790032
32,0
38,0
Red
20,0
MTR
0429790038
38,0
44,6
Red
20,0
MTR
0429790051
50,0
57,4
Red
20,0
MTR
0429790055
55,0
62,8
Red
20,0
MTR
0429790060
60,0
68,0
Red
20,0
MTR
0429790070
70,0
78,6
Red
20,0
MTR
0429790075
75,0
83,8
Red
20,0
MTR
0429790089
89,0
99,0
Red
20,0
MTR
