Milkland Flex

Application:

The hose is suitable for transporting milk and other foods.

Construction:

The Milkland Flex hose is made of natural rubber both inside and out. The hose is white and smooth on the inside and blue on the outside with canvas structure. The hose is built around a steel spiral for extra great flexibility.

Designed for tasteless and odorless transport of media
Built-in steel spiral
Ozone and weather-resistant

Download data sheet Go to hose assembly

Technical specifications

Temperature:

The temperature ranges from -30°C to +85°C.
The hose can be sterilized at +120°C for a maximum of 30 minutes.

Safety factor:

Safety factor: ≥ 3 times working pressure.

Pressure:

All pressures are stated at the temperature +20°C.

Standards:

EC 1935/2004 and 2023/2006/EC (GMP), FDA, D.M. 21.03.73, and BfR. The material is free of animal derivatives, phthalates, and adipates. Materials subject to restrictions according to EC 1907/2006 (REACH) Batch number for full traceability.

Approvals

Product number	Inner dia. mm	Outer dia. mm	Bending radius mm.	Working pressure bar	Burst pressure bar	Vacuum bar	Color	Metres per coil	Net weight kg.	Base unit
0401010257	25,0	36,0	50,0	6,0	18,0	0,90	Blue	40,0	0,70	MTR
0401010387	38,0	50,0	75,0	6,0	18,0	0,90	Blue	40,0	1,10	MTR
0401010407	40,0	52,0	80,0	6,0	18,0	0,9	Blue	40,0	1,10	MTR
0401010457	45,0	57,0	90,0	6,0	18,0	0,9	Blue	40,0	1,25	MTR
0401010517	51,0	63,0	100,0	6,0	18,0	0,90	Blue	40,0	1,45	MTR
0401010647	63,5	76,5	130,0	6,0	18,0	0,90	Blue	40,0	1,90	MTR
0401010767	76,0	90,0	155,0	6,0	18,0	0,90	Blue	40,0	2,65	MTR
