Oily Food/10-SLIDE

Application:

The hose is suitable for transporting oily and fatty foods.

Construction:

Oily Food/10-SLIDE is made of NBR on the inside and neoprene on the outside as well as coated on the outside with UPE liner for optimal hygiene. The hose is reinforced with synthetic fabric for extra great flexibility. The hose is white and smooth on the inside and blue with canvas structure on the outside.

  • Designed for tasteless and odourless transport of media
  • Resistant to animal and vegetable fats
  • The hose is dirt-repellent
  • Ozone and weather resistant

Technical specifications

Temperature:

The temperature ranges from -20°C to +90°C.
The hose can be sterilized at +130°C for a maximum of 30 minutes.

Safety factor:

Safety factor: ≥ 3 times working pressure.

Pressure:

All pressures are stated at the temperature +20°C.

Standards:

EC 1935/2004, 2023/2006/EC (GMP), FDA Standards 177.2600, D.M. 21/03/73, and BfR. The material is free of animal derivatives, phthalates, and adipates. Materials subject to restrictions according to EC 1907/2006 (REACH) Batch number for full traceability.

Approvals

Product number Inner dia.
mm
Outer dia.
mm
Bending radius
mm
Working pressure
bar
Burst pressure
bar
Vacuum
bar
Color Metres per
coil
Net weight
kg
Base unit
0417100100
10,0
20,0
70,0
10,0
30,0
0,80
Blue
40
0,25
PCS
0417100130
13,0
23,0
80,0
10,0
30,0
0,80
Blue
40
0,35
PCS
0417100160
16,0
28,0
100,0
10,0
30,0
0,80
Blue
40
0,41
PCS
0417100200
19,0
31,0
120,0
10,0
30,0
0,65
Blue
40
0,47
PCS
0417100250
25,0
37,0
150,0
10,0
30,0
0,65
Blue
40
0,77
PCS
