JOHNSON Acculobe mechanical seal

Application:

Shaft seal for Johnson Acculobe pump.

Construction:

  • The rotating part is driven by two pins
  • The seat is equipped with O-ring and two slots holding it in position
  • Provided with an O-ring that acts as secondary seal around the shaft
  • Is not directional



Technical specifications

Quality:

  • Gaskets in Viton
  • The slide ring is in silicon
  • The seat is made of silicon
Product number Shaft dia.
mm
Rotating part
material
Stationary part
material
Elastomer
type
Base unit
03452870247V
24,0
Sic
Sic
Viton
PCS
