IBEX MOG mechanical seal

Application:

Shaft seal for SSP pumps IBEX MOG, 1 1/8”, 1 3/8”, 2” & 3”.

Construction:

  • Shaft seal with wave spring
  • The rotating part is held on shaft with three screws
  • The seat is equipped with O-ring and pin holding it in position
  • Provided with an O-ring that acts as secondary seal around the shaft
  • Is not directional
  • The compression spring is external

Technical specifications

Quality:

  • Spring in stainless steel
  • Gaskets in either nitrile or EPDM
  • The slide ring is in carbon or silicon
  • The seat is made of stainless steel or silicon
Product number Shaft dia.
mm
Rotating part
material
Stationary part
material
Elastomer
type
Base unit
0345280M151N
15,0
Kul
Stainless
NBR
PCS
0345280M301E
30,1 ( 1.188" )
Kul
Stainless
EPDM
PCS
0345280M301N
30,1 ( 1.188" )
Kul
Stainless
NBR
PCS
0345280M307E
30,1 ( 1.188" )
Sic
Sic
EPDM
PCS
0345280M307V
30,1 ( 1.188" )
Sic
Sic
Viton
PCS
0345280M309V
30,1 ( 1.188" )
Tc
Tc
Viton
PCS
0345280M351E
34,9 ( 1.375" )
Kul
Stainless
EPDM
PCS
0345280M351N
34,9 ( 1.375" )
Kul
Stainless
NBR
PCS
0345280M357E
34,9 ( 1.375" )
Sic
Sic
EPDM
PCS
0345280M511E
50,8 ( 2" )
Kul
Stainless
EPDM
PCS
0345280M517E
50,8 ( 2" )
Sic
Sic
EPDM
PCS
0345280M761E
76,2 ( 3" )
Kul
Stainless
EPDM
PCS
0345280M761V
76,2 ( 3" )
Kul
Stainless
Viton
PCS
