ISO Clamp liner

Construction:

The fitting consists of a connection piece and a sleeve that are pressed together under great pressure and thus creates a strong and very smooth transition between the hose and the fitting.

  • Supplied for Clamp connection
  • Connections between 25.0 mm and up to 76.0 mm

Quality:

The connection piece is made of stainless steel AISI 316 with a surface roughness inside of R 0.8 µ and provided with batch number. The sleeve is made of stainless steel AISI 304.

Product number Nominal dim.
mm.
Connection
Clamp liner
Ø ID hose
mm
Ø OD hose
mm
Length L
mm
Base unit
0464132004
13,0
25,0
13,0
20,0
47
PCS
0464132204
13,0
25,0
13,0
22,0
47,0
PCS
0464132304
13,0
25,0
13,0
23,0
47
PCS
0464132504
13,0
25,0
13,0
25,0
47
PCS
0464192804
19,0
25,0
19,0
28,0
54,6
PCS
0464193104
19,0
25,0
19,0
31,0
54,6
PCS
0464253004
25,0
25,0
25,0
30,0
67,2
PCS
0464253704
25,0
25,0
25,0
37,0
67,2
PCS
0464253707
25,0
38,0
25,0
37,0
63,6
PCS
0464253708
25,0
51,0
25,0
37,0
66,3
PCS
0464253904
25,0
25,0
25,0
39,0
67,2
PCS
Product number Nominal dim.
mm.
Connection
Clamp liner
Ø ID hose
mm
Ø OD hose
mm
Length L
mm
Base unit
0464253906
25,0
38,0
25,0
39,0
63,6
PCS
0464324004
32,0
38,0
32,0
40,0
66,1
PCS
0464324004K
32,0
38,0
32,0
40,0
56,1
PCS
0464324014K
32,0
25,0
32,0
40,0
56,1
PCS
0464324404
32,0
38,0
32,0
44,0
66,1
PCS
0464384204
38,0
38,0
38,0
42,0
66,1
PCS
0464384404K
38,0
38,0
38,0
40,0
45,5
PCS
0464384904
38,0
38,0
38,0
49,0
66,1
PCS
0464384904K
38,0
38,0
38,0
49,0
45,5
PCS
0464385104
38,0
38,0
38,0
51,0
66,1
PCS
Product number Nominal dim.
mm.
Connection
Clamp liner
Ø ID hose
mm
Ø OD hose
mm
Length L
mm
Base unit
0464385104K
38,0
38,0
38,0
51,0
45,5
PCS
0464385110
38,0
51,0
38,0
51,0
64,8
PCS
0464385304
38,0
38,0
38,0
53,0
66,5
PCS
0464385604
38,0
38,0
38,0
56,0
66,1
PCS
0464516404
51,0
51,0
51,0
64,0
80,3
PCS
0464516410
51,0
63,5
51,0
64,0
80,3
PCS
0464516604
51,0
51,0
51,0
66,0
80,3
PCS
0464516610
51,0
63,5
51,0
66,0
80,3
PCS
0464517004
51,0
51,0
51,0
70,0
80,3
PCS
0464647504
63,5
63,5
63,5
75,0
94,8
PCS
Product number Nominal dim.
mm.
Connection
Clamp liner
Ø ID hose
mm
Ø OD hose
mm
Length L
mm
Base unit
0464647509
63,5
76,1
63,5
75,0
98,4
PCS
0464647804
63,5
63,5
63,5
78,0
94,8
PCS
0464648004
63,5
63,5
63,5
80,0
94,8
PCS
0464648804
63,5
63,5
63,5
88,0
94,8
PCS
0464768804
76,1
76,0
76,1
88,0
102,3
PCS
0464769204
76,1
76,0
76,1
92,0
102,3
PCS
0464769404
76,1
76,0
76,1
94,0
102,3
PCS
0464769904
76,1
76,0
76,1
101,0
102,3
PCS
0464991804
101,6
102,0
101,6
118,0
132,8
PCS
0464992004
101,6
102,0
101,6
120,0
132,8
PCS
Product number Nominal dim.
mm.
Connection
Clamp liner
Ø ID hose
mm
Ø OD hose
mm
Length L
mm
Base unit
