Silo/SPL-4BN

Application:

Silo is a suction and pressure hose for transporting granulates such as flour, animal feed, grain, and other powdered products.

Construction:

Silo is made of natural rubber and reinforced with steel spiral as well as high-strength fabric and copper wire for dissipation of static electricity. The hose is light and smooth with canvas structure on the outside.

  • Antistatic R <106
  • Optimal hygiene
  • Wear, ozone, and weather resistant

Technical specifications

Temperature:

The temperature ranges from -30°C to +60°C.
Briefly up to+80°C.

Safety factor:

Safety factor: ≥ 3 times working pressure.





Pressure:

All pressures are stated at the temperature +20°C.

Standards:

EC 1935/2004 and 2023/2006/EC (GMP), FDA, D.M. 21.03.73, as well as BgVV. The material is free of animal derivates, phthalates, and adipates. Materials subject to restriction according to EC 1907/2006 (REACH) Batch number for full traceability.

Approvals

Product number Inner dia.
mm
Outer dia.
mm
Bending radius
mm.
Working pressure
bar
Burst pressure
bar
Vacuum
bar
Color Metres per
coil
Net weight
kg.
Base unit
0427200510
51,0
67,0
300,0
4,0
12,0
0,68
Black
40,0
1,960
MTR
0427200640
63,5
80,0
390,0
4,0
12,0
0,68
Black
40,0
2,720
MTR
0427200760
76,0
92,0
450,0
4,0
12,0
0,68
Black
40,0
3,060
MTR
0427201020
102,0
120,0
600,0
4,0
12,0
0,68
Black
40,0
4,750
MTR
