Milkland Flex

Application:

Milk hose suitable for transporting milk and other food products.

Construction:

The Milkland Flex hose is made of natural rubber both inside and out. The hose is white and smooth on the inside and blue on the outside with canvas structure. The hose is built around a steel spiral for extra great flexibility.

  • Designed for tasteless and odorless transport of media
  • Built-in steel spiral
  • Ozone and weather resistant

Temperature:

The temperature ranges from -30°C to +85°C.
The hose can be sterilized at +120°C for a maximum of 30 minutes.

Safety factor:

Safety factor: ≥ 3 times working pressure.

Pressure:

All pressures are stated at the temperature +20°C.

Standards:

EC 1935/2004, 2023/2006/EC (GMP), RoHS, DM 21.03.73, EC 1907/2006 (REACH), FDA CFR 21-177.2600, BfR. The material is free from bisphenol A (BPA), animal derivatives, phthalates and adipates. Supplied with batch number for full traceability.

Approvals:

EU 1935 2004 Blue Rgb GMP 2023 2006 Blue Rgb Rohs Blue Rgb Dm21037 Blue Rgb Fda Food Quality Blue Rgb Bfr Blue Rgb Bpa Free Blue Rgb Phthalates Free Blue Rgb Animal Derivatives Free Blue Rgb Adi Free Blue Rgb Knivoggafel Blue Rgb
Download data sheet
Item number Inner dia.
mm
Outer dia.
mm
Bending radius
mm.
Working pressure
bar
Burst pressure
bar
Vacuum
bar
Color Metres per
coil
Net weight
kg.
Base unit Quantity
0401010257 25,0 36,0 50,0 6,0 18,0 0,90 Blue 40,0 0,70 MTR
0401010387 38,0 50,0 75,0 6,0 18,0 0,90 Blue 40,0 1,10 MTR
0401010407 40,0 52,0 80,0 6,0 18,0 0,9 Blue 40,0 1,10 MTR
0401010457 45,0 57,0 90,0 6,0 18,0 0,9 Blue 40,0 1,25 MTR
0401010517 51,0 63,0 100,0 6,0 18,0 0,90 Blue 40,0 1,45 MTR
0401010647 63,5 76,5 130,0 6,0 18,0 0,90 Blue 40,0 1,90 MTR
0401010767 76,0 90,0 155,0 6,0 18,0 0,90 Blue 40,0 2,65 MTR
Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
