Ball valve, 3-part with ISO top

Application:

3-part ball valve with ISO top for shutting off liquids, including saturated stem. Can be mounted with air-controlled actuator.

Construction:

  • Smooth and easy-to-clean exterior surface
  • Handle with automatic safety lock
  • Straight with female BSP
  • Full passage

Quality:

  • Made of stainless steel AISI 316
  • Gasket made of PTFE

Operating conditions:

  • The temperature covers from -50°C to +220°C
  • Steam: Max. 15 bar at +180°C
  • Pressure: Max. 70 bar
Download data sheet
Item number Nominal dim.
inch		 Connection
RG		 Length L
mm.		 Height H
mm.		 Working pressure
bar		 Net weight
kg.		 Base unit Quantity
0526039080 3/8" 3/8" 63,5 65,0 69,0 0,400 PCS
0526039100 1/2" 1/2" 65,5 65,0 69,0 0,600 PCS
0526039130 3/4" 3/4" 76,2 68,0 69,0 0,800 PCS
0526039150 1" 1" 86,0 71,0 69,0 1,100 PCS
0526039170 1 1/4" 1 1/4" 102,8 78,0 69,0 1,700 PCS
0526039190 1 1/2" 1 1/2" 119,0 86,0 69,0 2,600 PCS
0526039230 2" 2" 131,4 95,0 69,0 3,200 PCS
Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
