Alichem/SPL

Application:

Hose suitable for light chemical liquids and CIP cleaning.
The hose can also be used for non-fatty foods.

Construction:

Alichem SPL is a suction and pressure hose made of smooth EPDM on the inside. The hose is built around a steel spiral.

  • Exterior: durable and weather resistant synthetic rubber
  • Reinforced with several layers of polyester



Technical specifications

Temperature:

Temperatures from -40°C to +120°C depending on the media.
Can be sterilized at +140°C for a maximum of 30 minutes.

Safety factor:

Safety factor: ≥ 3 times working pressure.

Pressure:

All pressures are stated at the temperature +20°C.

Standards:

EC 1935/2004, 2023/2006/EC (GMP), FDA Standards 177.2600, D.M. 21/03/73 as well as BfR. The material is free of animal derivates, phthalates, and adipates. Materials subject to restriction according to EC 1907/2006 (REACH) Batch number for full traceability.

Approvals

Product number Inner dia.
mm
Outer dia.
mm
Bending radius
mm
Working pressure
bar
Burst pressure
bar
Vacuum
bar
Color Metres per
coil
Net weight
kg
Base unit
0428100200
19,0
31,0
80,0
10,0
30,0
0,90
Green
40,0
0,650
MTR
0428100250
25,0
37,0
120,0
10,0
30,0
0,90
Green
40,0
0,800
MTR
0428100320
32,0
44,0
150,0
10,0
30,0
0,90
Green
40,0
0,960
MTR
0428100380
38,0
52,0
200,0
10,0
30,0
0,90
Green
40,0
1,420
MTR
0428100510
51,0
65,0
250,0
10,0
30,0
0,90
Green
40,0
1,800
MTR
0428100640
63,5
79,5
360,0
10,0
30,0
0,90
Green
40,0
2,670
MTR
0428100760
76,0
92,0
450,0
10,0
30,0
0,90
Green
40,0
3,100
MTR
0428101020
102,0
120,0
600,0
10,0
30,0
0,90
Green
40,0
4,800
MTR
