Silicone hose, transparent, Peroxid cured

Application:

Silicone hose without inserts suitable for food and pharmaceutical industries.
For example, for laboratories where high demands are made on the temperature range.

Construction:

The hose is made of transparent silicone Peroxid, smooth on the inside. The silicone hose can withstand high temperatures and is very flexible.
Hardness: Shore 60.

Technical specifications

Temperature:

The temperature ranges from -40°C to +200°C.
The hose can be autoclaved.

Pressure:

All pressures are stated at the temperature +20°C.

Standards:

FDA (Title 21 CFR 177.2600), EC 1935/2004, BfR XV, ISO 9001:2015, ISO 13485:2016, as well as parts of ISO 10993.
The hose can be delivered in a version that complies with US Pharmacopeia, USP Class VI, E.p.3.1.9 (European Phamacopeia).

Approvals

Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200001003
1,0
3,0
Transparent
25,0
MTR
042200002004
2,0
4,0
Transparent
25,0
MTR
042200002006
2,0
6,0
Transparent
25,0
MTR
042200003004
3,0
4,0
Transparent
25,0
MTR
042200003005
3,0
5,0
Transparent
25,0
MTR
042200003006
3,0
6,0
Transparent
25,0
MTR
042200003007
3,0
7,0
Transparent
25,0
MTR
042200004006
4,0
6,0
Transparent
25,0
MTR
042200004007
4,0
7,0
Transparent
25,0
MTR
042200004008
4,0
8,0
Transparent
25,0
MTR
042200004009
4,0
9,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200004010
4,0
10,0
Transparent
25,0
MTR
042200005008
5,0
8,0
Transparent
25,0
MTR
042200005009
5,0
9,0
Transparent
25,0
MTR
042200006008
6,0
8,0
Transparent
25,0
MTR
042200006010
6,0
10,0
Transparent
25,0
MTR
042200006012
6,0
12,0
Transparent
25,0
MTR
042200007013
7,0
13,0
Transparent
25,0
MTR
042200008010
8,0
10,0
Transparent
25,0
MTR
042200008012
8,0
12,0
Transparent
25,0
MTR
042200008014
8,0
14,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200008514
8,5
14,0
Transparent
25,0
MTR
042200010014
10,0
14,0
Transparent
25,0
MTR
042200010014S
10,0
14,0
Black
25,0
MTR
042200010015
10,0
15,0
Transparent
25,0
MTR
042200011016
11,0
16,0
Transparent
25,0
MTR
042200012016
12,0
16,0
Transparent
25,0
MTR
042200012018
12,0
18,0
Transparent
25,0
MTR
042200012020
12,0
20,0
Transparent
25,0
MTR
042200012721
12,7
21,2
Transparent
25,0
MTR
042200013019
13,0
19,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200014022
14,0
22,0
Transparent
25,0
MTR
042200015019
15,0
19,0
Transparent
25,0
MTR
042200015021
15,0
21,0
Transparent
25,0
MTR
042200016020
16,0
20,0
Transparent
25,0
MTR
042200016021S
16,0
21,0
Black
25,0
MTR
042200016022
16,0
22,0
Transparent
25,0
MTR
042200019023
19,0
23,0
Transparent
25,0
MTR
042200019025
19,0
25,0
Transparent
25,0
MTR
042200019028
19,0
28,6
Transparent
25,0
MTR
042200020024
20,0
24,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200020026
20,0
26,0
Transparent
25,0
MTR
042200022026
22,0
26,0
Transparent
25,0
MTR
042200025029
25,0
29,0
Transparent
25,0
MTR
042200025031
25,0
31,0
Transparent
25,0
MTR
042200025033
25,0
33,0
Transparent
25,0
MTR
042200030036
30,0
36,0
Transparent
25,0
MTR
042200030038
30,0
38,0
Transparent
25
mtr
042200032036
32,0
36,0
Transparent
25,0
MTR
042200032038
32,0
38,0
Transparent
25,0
MTR
042200036040
36,0
40,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200038042
38,0
42,0
Transparent
25,0
MTR
042200038046
38,0
46,0
Transparent
25,0
MTR
042200038048
38,0
48,0
Transparent
25,0
MTR
042200040048
40,0
48,0
Transparent
25,0
MTR
042200044055
44,0
55,0
Transparent
25,0
MTR
042200050056
50,0
56,0
Transparent
25,0
MTR
042200052058
52,0
58,0
Transparent
25,0
MTR
042200064070
63,5
70,0
Transparent
25,0
MTR
042200075079
75,0
79,0
Transparent
25,0
MTR
042200076086
76,0
86,0
Transparent
25,0
MTR
Product number Inner dia.
mm
Outer dia.
mm
Color Metres per
coil
Base unit
042200085091
85,0
91,0
Transparent
25,0
MTR
042200090096
90,0
96,0
Transparent
25,0
MTR
